| model | HW936 |
| engine | Cummins QSB5.9-220 (National III) |
| power KW | 162 |
| Drill pipe type mm | 76*3000 |
| Drilling diametermm | 90-115 |
| Maximum working torque N.m | 2700 |
| Swing speed rpm | 70-150 |
| Propulsion kN | 15 |
| Lifting power kN | 25 |
| Propulsion method | Motor + chain |
| Leveling angle | 10 |
| Walking speed km/h | 1.5-3 |
| Gradeability | 30 |
| gross weight kg | 9400 |
| Shipping dimensions mm | 8000*2300*2600 |
| exhaust volume | Displacement 16m3/min. Pressure 16bar |
Thank you for providing the updated information about the DTH drilling rig.Main feature:1. The HW936 model is specifically designed for drilling blast holes with a diameter range of 90-115mm, which aligns with the mentioned specifications.2. The rig is equipped with a dry dust collector, which helps in minimizing environmental pollution. It also features a drill pipe changer, allowing for fficient and convenient pipe replacement during drilling operations. The rig incorporates advanced design and layout for enhanced performance.3. The HW-936 model, purpose-built for hard strata conditions, is a suitable choice for metal, limestone, dolomite, and aggregate open cast quarries and mines.Get the Best Down-the-Hole Drilling Rig for Your Projects!Explore our top-quality down-the-hole drilling rigs, engineered for precision, power, and durability in every drilling operation. ill out the form below to receive a personalized quote and expert guidance with no obligation.Why Choose Our Drilling Rigs ransparent Pricing: Receive a clear and detailed quote.High Quality: Robust and reliable equipment for any drilling project.Fast Shipping: Get your drilling rig delivered quickly and efficiently.Excellent After-Sales Service: Continuous support and effective solutions for your needs.Don t miss out! Complete the form and take the first step toward successful drilling with cutting-edge technology.
