Mainly for the large-area cement floor and professional ultra-flat ground pulping, compaction, smoothing, smearing;
-
It is equipped with honda gasoline engine, quality assurance, superior performance and easy start-up;
-
Gearbox with large modulus design, aluminum alloy case, maintenance-free and long service life;
-
The trowel blade support arm is made of ultra-large-diameter carbon structural steel which is strictly heat-treated, which can adapt to the individual workers operation;
-
The scientifically designed centrifugal clutch transmission mechanism has large transmission torque, long service life and convenient maintenance;
-
Low center of gravity design makes the machine run smoothly and flexibly;
-
The surface adopt plastic sprayed, beautiful , rust and corrosion resistant.
|
Model |
HWP-1000 |
|
Engine mode |
Honda GX690 |
|
Efficiency |
24hp/3600rpm |
|
Disk diameter |
1000mm |
|
Work speed |
0-135rpm |
|
Spatula piece number |
2×4 pcs |
|
The size of the spatula |
310??150mm |
|
Engine type |
Two cylinder,air cooled four stroke gasoline engine |
|
Tank capacity |
20L |
|
Lubricating oil quantity |
1.8L |
|
Fuel consumption |
313g/kwh |
|
Operation mode |
Driving operation |
|
0utline size (L*W*H) |
2100*1000*1050mm |
|
Weight |
380kg |
